The Air-Cooled Induction Cap Sealing Machine (Model JI-2000A) operates at 20m/min, accommodating diverse bottles with adjustable sealing height, featuring enhanced security and ideal for hygiene-focused environments, ensuring precision and cleanliness.


Key Features

  • Microcontroller based induction sealer.
  • Customised sealing heads for different types of closure profiles.
  • IGBT based power system for stable power delivery.
  • Air-cooled and water-cooled based induction sealer systems are available based on the demands of the application.
  • Three phase system also available. This reduces the ripple factor and balanced load is maintained.
  • Optional Conveyor with induction sealer
  • Optional NO Wad system with rejection system.
  • Optional stall bottle system .

Technical Specifications

Speed of Operation 20 m/min (Conveyor speed Max)
Bottle/Container MOC HDPE / PET / PP / Glass
Bottle Height/Adjustable Sealing Height 230 mm
Diameter of Closure 20 mm - 100 mm
Machine Type Automatic
Power Supply Req. 415/230 VAC, 50 Hz, 2 KW Max.
Air Supply Req. 1 CFM at 2 to 4 Kg/cm²
Main Frame MOC MSEP / SS316 / SS304
Dimensions 640 mm × 420 mm × 370 mm
Conveyor Type SS Slat Chain 4.5" width & varies according to bottle width
Conveyor MOC SS304 C Channel
Conveyor Dimensions 2.5 m × 1.5 m × 2 m
Other Details Micro Programmed, Password Protection setting for Enhanced Security, Auto detection of Sensors to activate Cap Inspection feature, No Foil & Stall/Jam Bottle Detection. Speed can vary according to the bottle size, speed of conveyor and sealing time.
